| RWMA Class | Alloy Name | Form | Hardness (HRB/ HRC) | Electrical Conductivity (IACS %) | Tensile Strength (N/㎟ (Kgf/㎟)) | Elongation (%) | Application |
|---|---|---|---|---|---|---|---|
| Class 2 | CuCr | Bar | HRB 75＜ | 75＜ | 42 (412) | 15＜ | Mostly for mild steel, high tensile strength steel, and surface treated steel sheet (thin coated). |
| Class 2 | CrZuCu | Plate | HRB 65< | 75＜ | 39 (382) | 15＜ | |
| Class 2 | CrZuCu | Forging | HRB 65< | 75＜ | 39 (382) | 15＜ | |
| Class 20 | CuAl₂O₃ "DHOM" | Bar | HRB 80＜ | 75＜ | 490 (50) | 65＜ | Mostly for thick coated steel. |
